We model the job in Tekla Structures and produce the drawings your shop and erectors actually use: clear connection callouts, accurate bills of material and machine-ready files. We match your templates, title blocks, numbering and file formats, so the package drops straight into your workflow.
Every package goes through a multi-stage check before it ships. A detailer models it, a senior checker reviews it against design intent and AISC and IBC, and connection work gets review by an independently licensed PE. We clash-check in the model before anything reaches the shop.
Piece and assembly drawings for beams, columns, braces, trusses and miscellaneous steel.
Plans and elevations that show the field crew what goes where and in what order.
Accurate material lists that tie back to the model.
Machine-ready files straight from the model for your shop equipment.
Shear, moment and bracing connections, base plates and embeds drawn to the design. Connection design is sealed by an independently licensed PE when the job needs it.
Your templates, title blocks, numbering and file formats, every time.
Tekla Structures for steel models, with AutoCAD and Revit when your project needs them. We output CNC and DSTV files for the shop.
Cadlions LLC does not seal or certify documents. Where a job needs sealed calculations or connection design, that work is performed and sealed by an independently licensed Professional Engineer engaged for the project and licensed in its jurisdiction.
Detailing ships to clients anywhere in the United States. We also fabricate structural steel and deliver it, ready to erect, in Tennessee, Georgia, Alabama, Kentucky, Texas, Florida, South Carolina and North Carolina.
Send the drawings or RFP through the contact page or to info@cadlions.com. We typically respond within one business day.
Yes. A dedicated crew can carry your work from bid through shop drawings in your standards and platforms, and scale up for a deadline.
